ESS - Ballistic Glasses ICE 3LS NARO - 740-0017
ICE NARO™ (Interchangeable Component Eyeshield) is a lightweight, frameless design that offers full ballistic protection. Plus an unlimited field of view, a first-class optical visor and adjustable temples. The modular design gives you the ability to replace any component of the glasses and also allows you to attach a corrective insert.
ICE NARO™ is the first model of ballistic goggles designed specifically for smaller, narrower faces. All NARO™ series visors provide UVA/UVB protection. Meanwhile, their durability exceeds the ANSI Z87.1-2015 standard. In addition, the glasses have passed MIL-PRF-31013 ballistic testing with .15 caliber. Stowed in a case, the glasses will easily fit into any backpack.
Features:
- Modular design
- Ability to replace any component of the goggles
- Distortion-free visor
- Protection against UVA and UVB rays
- ToughZone™ technology to protect the visor from scratches
- Unlimited field of view
- Easy and quick replacement of the visor
- Flexible temples with PosiLock™ technology
- Superior comfort and no pressure points
- Comfortable, replaceable composite-silicone nose pad
- Elastic strap to keep glasses from getting lost
- U-RX™, P-2B™ and Vice™ corrective inserts available
- Nylon case included
ESS Eyewear VIEWS & SIZES CHARTERISTE
We invite you to read the Card of visors and sizes of ESS eyewear presenting information on:
- the value of the visible light transmission coefficient (VLT) for all models of the company's visors
- information about the impact resistance of ESS glasses
- dimensions of frames of all models of ESS glasses
- information about completing sets of ESS eyeglasses series - One, 3LS, 2X
| Technical data | |
|---|---|
| Visor material | Polycarbonate |
| Visor thickness | 2.4 mm |
| Visor color | Transparent, visible light transmission: 90% Yellow, visible light transmission: 85% Tinted, visible light transmission: 15% |
| Earpiece color | Black |
| Visor dimensions | Length: 144.5 mm Width at widest point: 48.7 mm Width at nose piece mounting point: 19.3 mm |
| Spacing of side mounting holes | 90.1 / 109.7 mm |
| Earpiece dimensions | Width at hinge point: 137.5 mm Thickness of temples: 2.5 - 5 mm |
| Weight of complete glasses | 26 g |
| Weight of the visor | 17 g |
| Nose piece weight | 3 g |
| Weight of temples | 6 g |
| Filters | 100% UVA/UVB |
| NSN | 4240-01-545-7923 |
Standards:
- Complies with American civilian standard ANSI Z87.1 - 2015.
- Complies with U.S. Army MIL SPEC MIL-PRF-31013 (Clause 3.5.1.1).
- CE quality mark, complies with European standards STANAG 2920/4296, EN 166:2005, EN 168:2005
- Frames conform to European CE EN 166 FT standard
- Transparent and yellow visor complying with European standard CE 2-2.1 FT K N
- Tinted visor complying with European standard CE 5-3.1 FT K N
- Complies with US Federal OSHA
Kit components:
- ICE NARO™ earmuffs
- Clear clear visor
- Smoke Gray tinted visor
- High contrast Hi-Def Yellow visor
- No Fog microfiber cloth
- Elastic neck strap
- Nylon case with composite clip
